The DSL180 lens is a Tailored DistortionTM, miniature SuperFisheyeTM lens designed with a field of view of up to 200 degrees on 1/5” to 1/2.8” format imagers with HD resolution. Special design techniques and hybrid design form are used to achieve increased magnification (angular resolution) off axis compared to a standard fisheye lens.

NIR versions: No IR cut filter

The DSL181 lens is a miniature SuperFisheyeTM lens with Tailored DistortionTM designed with a field of view of up to 190 degrees on 1/4” to 1/2” format imagers with HD resolution. The low F-number, thermal stability, and special distortion characteristics make this lens ideal for exterior based camera applications.

Key Features :

•  SuperFisheye FOV: 194°
•  Tailored DistortionTM
•  Superior low light performance: F/2.2 aperture
•  Compact size

Applications :

•  Automotive Surround View
•  Security and Surveillance
•  Internet of Things (IoT)
•  Computer Vision

DSL208 lens is a miniature glass lens optimized for HD imagers up to 1/3” format with HD resolution. This lens is Day/Night optimized and is near infrared corrected.

Available in NIR versions: No IR cut filter

DSL208A-650-F4.0 lens is a miniature glass lens optimized for HD imagers up to 1/3” format with HD resolution. This lens is Day/Night optimized and is near infrared corrected.

Available in NIR versions: No IR cut filter

The DSL213 is a miniature wide-angle and Day/Night lens designed for 1/3” format imagers with up to 2MP resolution. The Near Infrared correction and low F/# make this lens ideal for compact applications using active 850nm or 940nm light sources, and those used in low light situations.

NIR versions: No IR cut filter

The DSL235 is a miniature wide angle lens designed for 2-3MP image sensors with 1/3” format. The DSL235 isoptimized for Day/Night applications with active illumination in the Near Infrared, which makes it ideal for space constrained applications utilizing 850nm or 940nm active illumination.

The DSL255 is an all-glass, miniature SuperFisheyeTM lens designed for 4K sensors with up to 1/2” format size. The SuperFisheyeTM design provides a FOV of 190 ̊ at design image circle of 4.3mm. The low F-number, compact size and thermal stability make this lens ideal for security and other high-quality indoor/outdoor imaging applications.

DSL355A-650-F2.8

Key Features :

• Miniature Wide Angle Lens
• Compact size
• High image quality
• Low distortion

Applications :

• Security / Surveillance
• Telecommunications / Video-Conferencing
• Action Cameras

The DSL401 is a miniature Tailored DistortionTM wide- angle lens designed for 4K+ HDR sensors with up to 1/2” format size. The compact size, low distortion and high image quality make this lens ideal for space constrained camera systems requiring minimal, if any, distortion correction in the ISP or software.

DSL419B-650-F2.0

Key Features :

•  SuperFisheye FOV: 180°
•  All-Glass Design•  Good low light performance: F/2.0 aperture
•  Compact size

Applications :

• Security and Surveillance
• Drones
• Immersive Imaging
• Video Communication
• Consumer Devices and IoT

The DSL949 is a hybrid lens designed for 1/3” imagers withup to 5MP resolution. Special design techniques enable the DSL949 to achieve a wider than normal field of view with very low distortion in a small form factor.
