Lens DSL355

Key Features:

•  Maximum field of view (FOV): 180o
•  All glass design to optimize thermal stability
•  F/2.0 for superior low-light performance

Application :

• Security/Surveillance
• Consumer imaging
• Automotive surround view

Key Features :

•  Low F/# for optimal low-light performance
•  All glass elements provide environmental stability
•  Cost effective construction

Applications :

•  Security/Surveillance Dome Cameras
•  Automotive surround view

DSL311A 650F2.8

Key Features :

• 151° FOV
• F/2.8
• 22mm TTL

Applications:

• Security/Surveillance
• Automotive Rear-view
• Sports and Wearable Cameras

DSL322A-650-F2.0

Key Features :

• Miniature Wide Angle Day/Night Lens
• Compact design
• High image quality
• Wide angle design

Applications :

• Security / Surveillance
• Computer Vision

The DSL202 lens is a multi-element glass lens optimized for imager sizes up to 1/3" format and HD resolution. The all glass, all metal construction enables good thermal stability. The DSL202 is also environmentally ruggedized

Key Features :

• Wide field of view : 126 deg HFOV on 1/3” imager
• Excellent low light performance: F/2.0 aperture
• All glass elements providing environmental stability
• Distortion: f-θ type (image height is proportional to the input angle h=f*θ where f is the focal length).

DSL203A Wide Angle Security Lens

Key Features :

• Designed for multi-megapixel resolution sensors
• Full field of view of up to 140°
• High brightness, F/2.6 aperture
• All glass design provides environmental stability

Applications :

• Security and surveillance
• Automotive rear view cameras

The DSL901 is a multi-element glass lens designed for 2/3” imagers with up to 1.3MP resolution. The compact form factor of the DSL901 relative to the large imager format size makes this lens ideal for size constrained machine vision applications.

*NIR = without IR cut filter

Compatibility GoPro ® HERO 1 HERO 2 HERO 3, HERO 3+ and HERO 4®

This objective is part of a new optical generation. There is no better in technology .

This optical record with a field of view of 90 °.

The DSL147 is a high-performance, wide-angle, low-light lens with 4K resolution and F/1.4 aperture, designed for 1/3" and 1/2.8" HDR sensors. The all-glass construction makes it thermally stable and ideally-suited for indoor or outdoor applications in harsh environments.

The DSL935 lens is a multiple element glass lens optimized for 1/1.8” format imagers with up to 5MP resolution. The small form factor makes this lens ideal for high performance handheld cameras.

DSL239-650-F2.4
4K Miniature SuperFisheyeTM Lens

Key Features :

• SuperFisheye FOV: 186°
• Good low light perfomance : F/2.4 aperture
• 27,00mm TTL

Applications :

• Security and Surveillance cameras
•  Drone cameras
•  Immersive Imaging cameras

The DSL181 lens is a miniature SuperFisheyeTM lens with Tailored DistortionTM designed with a field of view of up to 190 degrees on 1/4” to 1/2” format imagers with HD resolution. The low F-number, thermal stability, and special distortion characteristics make this lens ideal for exterior based camera applications.

The DSL934B is a multi-element glass lens optimized for 3-5MP imagers with up to 1/1.8” format size. The compact size and all-glass all-metal construction make this lens ideal for applications requiring high resolution and temperature stability such as discreet outdoor security cameras.
