Lens DSL388

The DSL147 is a high-performance, wide-angle, low-light lens with 4K resolution and F/1.4 aperture, designed for 1/3" and 1/2.8" HDR sensors. The all-glass construction makes it thermally stable and ideally-suited for indoor or outdoor applications in harsh environments.

The DSL945 is a 4K lens designed for 1/2.3” imagers with up to 10MP resolution. The high resolution of this lens makes it ideal for scanning and finite conjugate machine vision applications.

Key Features  :

•  Wide angle, low distortion
•  High performance compact design
•  Finite conjugate optimized

Applications :

•  Document scanning
•  Video-conferencing
•  Finite Imaging

Key Features :

•  SuperFisheye FOV: 194°
•  Tailored DistortionTM
•  Superior low light performance: F/2.2 aperture
•  Compact size

Applications :

•  Automotive Surround View
•  Security and Surveillance
•  Internet of Things (IoT)
•  Computer Vision

Ultra-low F/# for superb low-light imaging in Automotive, Autonomous and Security related applications, 4K, Low-Ghost design provides excellent image quality.

• Hybrid lens for excellent image and distortion characteristics
• HDR-Optimized for Low flare and ghost
• High (4K) resolution and extremely low F/# for bright, sharp images.

DSL216 lens is a miniature, high-resolution SuperFisheyeTM lens designed to give a fisheye image with a horizontal field of view greater than 180 degrees on a 1/3” format sensor making it ideal for security or emerging applications like 360° cameras. Additionally, the DSL216 has an all-glass all-metal design which gives it thermal stability.

Key Features :

DSL208 lens is a miniature glass lens optimized for HD imagers up to 1/3” format with HD resolution. This lens is Day/Night optimized and is near infrared corrected.

Available in NIR versions: No IR cut filter

Key Features :

•  F/1.7 for enhanced low light sensitivity
•  All glass to optimize thermal stability
•  Low stray light for HDR sensors

Applications :

•  Automotive Forward Machine Vision (Sensing)
•  Automotive Mirror Replacement (CMS/eMirror)
•  Security Cameras
•  Computer Vision

DSL239-650-F2.4
4K Miniature SuperFisheyeTM Lens

Key Features :

• SuperFisheye FOV: 186°
• Good low light perfomance : F/2.4 aperture
• 27,00mm TTL

Applications :

• Security and Surveillance cameras
•  Drone cameras
•  Immersive Imaging cameras

The DSL255 is an all-glass, miniature SuperFisheyeTM lens designed for 4K sensors with up to 1/2” format size. The SuperFisheyeTM design provides a FOV of 190 ̊ at design image circle of 4.3mm. The low F-number, compact size and thermal stability make this lens ideal for security and other high-quality indoor/outdoor imaging applications.

Key Features :

•  Compact Size
•  F/1.6 for low light and high framerate cameras
•  Excellent thermal Stability
•  Optimized for HDR sensors

Application :

•  Automotive Forward Machine Vision (sensing)
•  Automotive Mirror Replacement (CMS/eMirror)
•  Object Recognition

The DSL977 is an all-glass lens designed for 1MP HDR imagers. Special optical design, coating and process techniques are applied to achieve the high resolution, low relative aperture eliminating lens ghosting (120dB) and minimize flare and stray light.

Key Features :

• NoGhost, low stray light for HDR sensors
• Low relative aperture F/1.8
• Face Sealed to IP6K9K
• Compact size

Key Features :

• Wide field of view : 126 deg HFOV on 1/3” imager
• Excellent low light performance: F/2.0 aperture
• All glass elements providing environmental stability
• Distortion: f-θ type (image height is proportional to the input angle h=f*θ where f is the focal length).

The DSL949 is a hybrid lens designed for 1/3” imagers withup to 5MP resolution. Special design techniques enable the DSL949 to achieve a wider than normal field of view with very low distortion in a small form factor.

DSL217C-670-F1.8

•  Maximum field of view (FOV): 185o
•  F/1.8 aperture for low-light performance
•  Hybrid glass-plastic design
•  Suitable for megapixel resolution sensors
